Grpc源码分析

func main() {
	flag.Parse()
	lis, err := net.Listen("tcp", fmt.Sprintf(":%d", *port))
	if err != nil {
		log.Fatalf("failed to listen: %v", err)
	}
	s := grpc.NewServer()
	pb.RegisterGreeterServer(s, &server{})
	log.Printf("server listening at %v", lis.Addr())
	if err := s.Serve(lis); err != nil {
		log.Fatalf("failed to serve: %v", err)
	}
}

func (s *Server) Serve(lis net.Listener) error {
	s.serve = true
	for {
		rawConn, err := lis.Accept()
		s.serveWG.Add(1)
		go func() {
			s.handleRawConn(lis.Addr().String(), rawConn)
			s.serveWG.Done()
		}()

}

func (s *Server) handleRawConn(lisAddr string, rawConn net.Conn) {
  // 如果grpc server已经关闭，那么同样关闭这个tcp连接
	if s.quit.HasFired() {
		rawConn.Close()
		return
	}
  // 设置tcp超时时间
	rawConn.SetDeadline(time.Now().Add(s.opts.connectionTimeout))

	// Finish handshaking (HTTP2)
	st := s.newHTTP2Transport(rawConn)
  // 清理tcp超时时间
	rawConn.SetDeadline(time.Time{})
  // rpc交互阶段，创建新的goroutine处理来自client的数据
	go func() {
		s.serveStreams(context.Background(), st, rawConn)
		s.removeConn(lisAddr, st)
	}()
}

func (s *Server) newHTTP2Transport(c net.Conn) transport.ServerTransport {
  // 组装 serverconfig
	config := &transport.ServerConfig{
		MaxStreams:            s.opts.maxConcurrentStreams,
		ConnectionTimeout:     s.opts.connectionTimeout,
		...
	}
  // 根据config的配置项，和client进行http2的握手
	st, err := transport.NewServerTransport(c, config)

	writeBufSize := config.WriteBufferSize
	readBufSize := config.ReadBufferSize
	maxHeaderListSize := defaultServerMaxHeaderListSize
	if config.MaxHeaderListSize != nil {
		maxHeaderListSize = *config.MaxHeaderListSize
	}
	framer := newFramer(conn, writeBufSize, readBufSize, config.SharedWriteBuffer, maxHeaderListSize)

// Send initial settings as connection preface to client.
isettings := []http2.Setting{{
  ID:  http2.SettingMaxFrameSize,
  Val: http2MaxFrameLen,
}}
if config.MaxStreams != math.MaxUint32 {
  isettings = append(isettings, http2.Setting{
    ID:  http2.SettingMaxConcurrentStreams,
    Val: config.MaxStreams,
  })
}
...

if err := framer.fr.WriteSettings(isettings...); err != nil {
  return nil, connectionErrorf(false, err, "transport: %v", err)
}

t := &http2Server{
  done:              done,
  conn:              conn,
  peer:              peer,
  framer:            framer,
  readerDone:        make(chan struct{}),
  loopyWriterDone:   make(chan struct{}),
  maxStreams:        config.MaxStreams,
  inTapHandle:       config.InTapHandle,
  fc:                &trInFlow{limit: uint32(icwz)},
  state:             reachable,
  activeStreams:     make(map[uint32]*ServerStream),
  stats:             config.StatsHandlers,
  kp:                kp,
  idle:              time.Now(),
  kep:               kep,
  initialWindowSize: iwz,
  bufferPool:        config.BufferPool,
}
// controlbuf用来缓存Setting Frame等和设置相关的Frame的缓存
t.controlBuf = newControlBuffer(t.done)
// 自增连接id
t.connectionID = atomic.AddUint64(&serverConnectionCounter, 1)
// flush framer，确保向client发送了setting frame
t.framer.writer.Flush()

// Check the validity of client preface.
preface := make([]byte, len(clientPreface))
// 读取客户端发来的client preface，并验证是否和预期一致
if _, err := io.ReadFull(t.conn, preface); err != nil {
  // In deployments where a gRPC server runs behind a cloud load balancer
  // which performs regular TCP level health checks, the connection is
  // closed immediately by the latter.  Returning io.EOF here allows the
  // grpc server implementation to recognize this scenario and suppress
  // logging to reduce spam.
  if err == io.EOF {
    return nil, io.EOF
  }
  return nil, connectionErrorf(false, err, "transport: http2Server.HandleStreams failed to receive the preface from client: %v", err)
}
if !bytes.Equal(preface, clientPreface) {
  return nil, connectionErrorf(false, nil, "transport: http2Server.HandleStreams received bogus greeting from client: %q", preface)
}

// 读取client端发来的frame
frame, err := t.framer.fr.ReadFrame()
if err == io.EOF || err == io.ErrUnexpectedEOF {
  return nil, err
}
if err != nil {
  return nil, connectionErrorf(false, err, "transport: http2Server.HandleStreams failed to read initial settings frame: %v", err)
}
atomic.StoreInt64(&t.lastRead, time.Now().UnixNano())
// 转成SettingFrame
sf, ok := frame.(*http2.SettingsFrame)
if !ok {
  return nil, connectionErrorf(false, nil, "transport: http2Server.HandleStreams saw invalid preface type %T from client", frame)
}
// 处理SettingFrame
t.handleSettings(sf)

func (t *http2Server) handleSettings(f *http2.SettingsFrame) {
  // 如果是ack frame，则直接返回
	if f.IsAck() {
		return
	}
	var ss []http2.Setting
	var updateFuncs []func()
	f.ForeachSetting(func(s http2.Setting) error {
		switch s.ID {
    // 更新http2Server中的配置信息
		case http2.SettingMaxHeaderListSize:
			updateFuncs = append(updateFuncs, func() {
				t.maxSendHeaderListSize = new(uint32)
				*t.maxSendHeaderListSize = s.Val
			})
		default:
			ss = append(ss, s)
		}
		return nil
	})
  // 这里又遇到了controlBuf
  // 执行updateFuncs()，然后将incommingSetting加入到controlBuf的队列中
	t.controlBuf.executeAndPut(func() bool {
		for _, f := range updateFuncs {
			f()
		}
		return true
	}, &incomingSettings{
		ss: ss,
	})
}

go func() {
  t.loopy = newLoopyWriter(serverSide, t.framer, t.controlBuf, t.bdpEst, t.conn, t.logger, t.outgoingGoAwayHandler, t.bufferPool)
  err := t.loopy.run()
  close(t.loopyWriterDone)
  if !isIOError(err) {
    timer := time.NewTimer(time.Second)
    defer timer.Stop()
    select {
    case <-t.readerDone:
    case <-timer.C:
    }
    t.conn.Close()
  }
}()
go t.keepalive()

// FrameType represents the type of an HTTP/2 Frame.
// See [Frame Type].
//
// [Frame Type]: https://httpwg.org/specs/rfc7540.html#FrameType
type FrameType uint8

// Frame types defined in the HTTP/2 Spec.
const (
	FrameTypeData         FrameType = 0x0
	FrameTypeHeaders      FrameType = 0x1
	FrameTypeRSTStream    FrameType = 0x3
	FrameTypeSettings     FrameType = 0x4
	FrameTypePing         FrameType = 0x6
	FrameTypeGoAway       FrameType = 0x7
	FrameTypeWindowUpdate FrameType = 0x8
	FrameTypeContinuation FrameType = 0x9
)

func (s *Server) serveStreams(ctx context.Context, st transport.ServerTransport, rawConn net.Conn) {
	streamQuota := newHandlerQuota(s.opts.maxConcurrentStreams)
  // 阻塞并接受来自client的frame
	st.HandleStreams(ctx, func(stream *transport.ServerStream) {
		s.handlersWG.Add(1)
		streamQuota.acquire()
		f := func() {
			defer streamQuota.release()
			defer s.handlersWG.Done()
      // 当一个新的stream被创建之后，进行一些配置
			s.handleStream(st, stream)
		}

		if s.opts.numServerWorkers > 0 {
			select {
			case s.serverWorkerChannel <- f:
				return
			default:
				// If all stream workers are busy, fallback to the default code path.
			}
		}
		go f()
	})
}

func (t *http2Server) HandleStreams(ctx context.Context, handle func(*ServerStream)) {
	defer func() {
		close(t.readerDone)
		<-t.loopyWriterDone
	}()
  // for循环，持续处理一个连接的上请求
	for {
    // 限流
		t.controlBuf.throttle()
    // 读取frame
		frame, err := t.framer.fr.ReadFrame()
		atomic.StoreInt64(&t.lastRead, time.Now().UnixNano())
    // 根据frame的类型分别处理
		switch frame := frame.(type) {
    // MetaHeaderFrame并不是http2的frame类型，而是经过包装的类型
    // headers frame + zero or more continuation frame + hspack编码内容的解码
		case *http2.MetaHeadersFrame:
			if err := t.operateHeaders(ctx, frame, handle); err != nil {
				// Any error processing client headers, e.g. invalid stream ID,
				// is considered a protocol violation.
				t.controlBuf.put(&goAway{
					code:      http2.ErrCodeProtocol,
					debugData: []byte(err.Error()),
					closeConn: err,
				})
				continue
			}
		case *http2.DataFrame:
			t.handleData(frame)
		case *http2.RSTStreamFrame:
			t.handleRSTStream(frame)
		case *http2.SettingsFrame:
			t.handleSettings(frame)
		case *http2.PingFrame:
			t.handlePing(frame)
		case *http2.WindowUpdateFrame:
			t.handleWindowUpdate(frame)
		case *http2.GoAwayFrame:
			// TODO: Handle GoAway from the client appropriately.
		default:
			if t.logger.V(logLevel) {
				t.logger.Infof("Received unsupported frame type %T", frame)
			}
		}
	}
}

func (t *http2Server) operateHeaders(ctx context.Context, frame *http2.MetaHeadersFrame, handle func(*ServerStream)) error {
	// Acquire max stream ID lock for entire duration
	t.maxStreamMu.Lock()
	defer t.maxStreamMu.Unlock()
	// 从客户端frame中获取streamID
	streamID := frame.Header().StreamID
	// 校验stream id
	if streamID%2 != 1 || streamID <= t.maxStreamID {
		// illegal gRPC stream id.
		return fmt.Errorf("received an illegal stream id: %v. headers frame: %+v", streamID, frame)
	}
  // 将获得的streamID设置到http2Server
	t.maxStreamID = streamID
	// 无界message缓冲
	buf := newRecvBuffer()
  // 创建stream
	s := &ServerStream{
		Stream: &Stream{
			id:  streamID,
			buf: buf,
			fc:  &inFlow{limit: uint32(t.initialWindowSize)},
		},
		st:               t,
		headerWireLength: int(frame.Header().Length),
	}

for _, hf := range frame.Fields {
  switch hf.Name {
  case "grpc-encoding":
    s.recvCompress = hf.Value
  case ":method":
    // POST, GET这些
    httpMethod = hf.Value
  case ":path":
    // 使用grpc那个服务的那个方法
    s.method = hf.Value
  case "grpc-timeout":
    timeoutSet = true
    var err error
    if timeout, err = decodeTimeout(hf.Value); err != nil {
      headerError = status.Newf(codes.Internal, "malformed grpc-timeout: %v", err)
    }
  }
}

st.HandleStreams(ctx, func(stream *transport.ServerStream) {
  s.handlersWG.Add(1)
  streamQuota.acquire()
  f := func() {
    defer streamQuota.release()
    defer s.handlersWG.Done()
    s.handleStream(st, stream)
  }
	// 如果设置了worker池，则先尝试提交任务到worker池中，如果不行，新起goroutine执行
  if s.opts.numServerWorkers > 0 {
    select {
    case s.serverWorkerChannel <- f:
      return
    default:
      // If all stream workers are busy, fallback to the default code path.
    }
  }
  go f()
})

// initServerWorkers creates worker goroutines and a channel to process incoming
// connections to reduce the time spent overall on runtime.morestack.
func (s *Server) initServerWorkers() {
	s.serverWorkerChannel = make(chan func())
	s.serverWorkerChannelClose = sync.OnceFunc(func() {
		close(s.serverWorkerChannel)
	})
	for i := uint32(0); i < s.opts.numServerWorkers; i++ {
		go s.serverWorker()
	}
}

func (s *Server) handleStream(t transport.ServerTransport, stream *transport.ServerStream) {
  // 获取grpc路径
	sm := stream.Method()
	pos := strings.LastIndex(sm, "/")
  // 调用的grpc service name
	service := sm[:pos]
  // 调用的grpc method name
	method := sm[pos+1:]

  // 从grpc server注册的service和method中找是否存在
	srv, knownService := s.services[service]
	if knownService {
    // unary rpc
		if md, ok := srv.methods[method]; ok {
			s.processUnaryRPC(ctx, stream, srv, md, ti)
			return
		}
    // stream rpc
		if sd, ok := srv.streams[method]; ok {
			s.processStreamingRPC(ctx, stream, srv, sd, ti)
			return
		}
	}
}

func (s *Server) processUnaryRPC(ctx context.Context, stream *transport.ServerStream, info *serviceInfo, md *MethodDesc, trInfo *traceInfo) (err error) {
  // 接收message并且解压缩
	d, err := recvAndDecompress(&parser{r: stream, bufferPool: s.opts.bufferPool}, stream, dc, s.opts.maxReceiveMessageSize, payInfo, decomp, true)
  df := func(v any) error {
    defer dataFree()
    // 使用proto codec将获取到的数据unmarshal到对应的请求类型
    if err := s.getCodec(stream.ContentSubtype()).Unmarshal(d, v); err != nil {
      return status.Errorf(codes.Internal, "grpc: error unmarshalling request: %v", err)
    }
    ...
	ctx = NewContextWithServerTransportStream(ctx, stream)
  // 调用实际的server端方法，得到返回结果
	reply, appErr := md.Handler(info.serviceImpl, ctx, df, s.opts.unaryInt)
  // Last=true表示stream最后的写操作，实际上好像没啥用
	opts := &transport.WriteOptions{Last: true}

	if err := s.sendResponse(ctx, stream, reply, cp, opts, comp); err != nil {
	return stream.WriteStatus(statusOK)
}

func recvAndDecompress(p *parser, s recvCompressor, dc Decompressor, maxReceiveMessageSize int, payInfo *payloadInfo, compressor encoding.Compressor, isServer bool,
) (out mem.BufferSlice, err error) {
	pf, compressed, err := p.recvMsg(maxReceiveMessageSize)
	compressedLength := compressed.Len()
	if pf.isCompressed() {
		defer compressed.Free()
		// To match legacy behavior, if the decompressor is set by WithDecompressor or RPCDecompressor,
		// use this decompressor as the default.
		out, err = decompress(compressor, compressed, dc, maxReceiveMessageSize, p.bufferPool)
		if err != nil {
			return nil, err
		}
	} else {
		out = compressed
	}

	if payInfo != nil {
		payInfo.compressedLength = compressedLength
		out.Ref()
		payInfo.uncompressedBytes = out
	}

	return out, nil
}

func (p *parser) recvMsg(maxReceiveMessageSize int) (payloadFormat, mem.BufferSlice, error) {
  // 读取message的header，总共5个字节
	err := p.r.ReadMessageHeader(p.header[:])
  // 是否压缩
	pf := payloadFormat(p.header[0])
  // 数据长度
	length := binary.BigEndian.Uint32(p.header[1:])
	// 读取数据
	data, err := p.r.Read(int(length))
	return pf, data, nil
}

func _Greeter_SayHello_Handler(srv interface{}, ctx context.Context, dec func(interface{}) error, interceptor grpc.UnaryServerInterceptor) (interface{}, error) {
	in := new(HelloRequest)
  // unmarshal操作
	if err := dec(in); err != nil {
		return nil, err
	}
	if interceptor == nil {
		return srv.(GreeterServer).SayHello(ctx, in)
	}
	info := &grpc.UnaryServerInfo{
		Server:     srv,
		FullMethod: Greeter_SayHello_FullMethodName,
	}
	handler := func(ctx context.Context, req interface{}) (interface{}, error) {
		return srv.(GreeterServer).SayHello(ctx, req.(*HelloRequest))
	}
	return interceptor(ctx, in, info, handler)
}

const (
	payloadLen = 1
	sizeLen    = 4
	headerLen  = payloadLen + sizeLen
)
// 这个方法很好理解，构造message header和payload
// msgHeader returns a 5-byte header for the message being transmitted and the
// payload, which is compData if non-nil or data otherwise.
func msgHeader(data, compData mem.BufferSlice, pf payloadFormat) (hdr []byte, payload mem.BufferSlice) {
	hdr = make([]byte, headerLen)
	hdr[0] = byte(pf)

	var length uint32
	if pf.isCompressed() {
		length = uint32(compData.Len())
		payload = compData
	} else {
		length = uint32(data.Len())
		payload = data
	}

	// Write length of payload into buf
	binary.BigEndian.PutUint32(hdr[payloadLen:], length)
	return hdr, payload
}

func (s *Server) sendResponse(ctx context.Context, stream *transport.ServerStream, msg any, cp Compressor, opts *transport.WriteOptions, comp encoding.Compressor) error {
  // 编码
	data, err := encode(s.getCodec(stream.ContentSubtype()), msg)
  // 压缩
	compData, pf, err := compress(data, cp, comp, s.opts.bufferPool)
  // 构造header和payload
	hdr, payload := msgHeader(data, compData, pf)
  // 交给http2server实际发送数据
	err = stream.Write(hdr, payload, opts)
}

// Write converts the data into HTTP2 data frame and sends it out. Non-nil error
// is returns if it fails (e.g., framing error, transport error).
func (t *http2Server) write(s *ServerStream, hdr []byte, data mem.BufferSlice, _ *WriteOptions) error {
	reader := data.Reader()

	if !s.isHeaderSent() { // Headers haven't been written yet.
		if err := t.writeHeader(s, nil); err != nil {
			_ = reader.Close()
			return err
		}
	} else {
		// Writing headers checks for this condition.
		if s.getState() == streamDone {
			_ = reader.Close()
			return t.streamContextErr(s)
		}
	}
	// 构造 data frame
	df := &dataFrame{
		streamID:    s.id,
		h:           hdr,
		reader:      reader,
		onEachWrite: t.setResetPingStrikes,
	}
  // 阻塞获取writeQuota
	if err := s.wq.get(int32(len(hdr) + df.reader.Remaining())); err != nil {
		_ = reader.Close()
		return t.streamContextErr(s)
	}
  // 将data frame放入controlBuf，异步发送
	if err := t.controlBuf.put(df); err != nil {
		_ = reader.Close()
		return err
	}
	t.incrMsgSent()
	return nil
}

func (t *http2Server) writeStatus(s *ServerStream, st *status.Status) error {
	s.hdrMu.Lock()
	defer s.hdrMu.Unlock()

	if s.getState() == streamDone {
		return nil
	}
	// Attach the trailer metadata.
	headerFields = appendHeaderFieldsFromMD(headerFields, s.trailer)
	trailingHeader := &headerFrame{
		streamID:  s.id,
		hf:        headerFields,
		endStream: true,
		onWrite:   t.setResetPingStrikes,
	}

	// Send a RST_STREAM after the trailers if the client has not already half-closed.
	rst := s.getState() == streamActive
  // 调用 finishStream关闭stream
	t.finishStream(s, rst, http2.ErrCodeNo, trailingHeader, true)
}

func (t *http2Server) handleData(f *http2.DataFrame) {
	size := f.Header().Length
	// Select the right stream to dispatch.
	s, ok := t.getStream(f)
	if !ok {
		return
	}
	if s.getState() == streamReadDone {
		t.closeStream(s, true, http2.ErrCodeStreamClosed, false)
		return
	}
	if size > 0 {
		if len(f.Data()) > 0 {
			pool := t.bufferPool
			s.write(recvMsg{buffer: mem.Copy(f.Data(), pool)})
		}
	}
	if f.StreamEnded() {
		// Received the end of stream from the client.
		s.compareAndSwapState(streamActive, streamReadDone)
		s.write(recvMsg{err: io.EOF})
	}
}

func (t *http2Server) handleSettings(f *http2.SettingsFrame) {
	if f.IsAck() {
		return
	}
	var ss []http2.Setting
	var updateFuncs []func()
	f.ForeachSetting(func(s http2.Setting) error {
		switch s.ID {
		case http2.SettingMaxHeaderListSize:
			updateFuncs = append(updateFuncs, func() {
				t.maxSendHeaderListSize = new(uint32)
				*t.maxSendHeaderListSize = s.Val
			})
		default:
			ss = append(ss, s)
		}
		return nil
	})
	t.controlBuf.executeAndPut(func() bool {
		for _, f := range updateFuncs {
			f()
		}
		return true
	}, &incomingSettings{
		ss: ss,
	})
}

type framer struct {
  // 一个包含了buffer的net.Conn的writer
	writer *bufWriter
  // 原生的http2.Framer，负责数据读写
	fr     *http2.Framer
}

// 全局writeBufferPool
var writeBufferPoolMap = make(map[int]*sync.Pool)
var writeBufferMutex sync.Mutex

func newFramer(conn net.Conn, writeBufferSize, readBufferSize int, sharedWriteBuffer bool, maxHeaderListSize uint32) *framer {
	if writeBufferSize < 0 {
		writeBufferSize = 0
	}
	var r io.Reader = conn
	if readBufferSize > 0 {
    // 设置io.Reader
		r = bufio.NewReaderSize(r, readBufferSize)
	}
	var pool *sync.Pool
	if sharedWriteBuffer {
		pool = getWriteBufferPool(writeBufferSize)
	}
  // 设置io.Writer
	w := newBufWriter(conn, writeBufferSize, pool)
  // 创建framer
	f := &framer{
		writer: w,
		fr:     http2.NewFramer(w, r),
	}
	f.fr.SetMaxReadFrameSize(http2MaxFrameLen)
	// Opt-in to Frame reuse API on framer to reduce garbage.
	// Frames aren't safe to read from after a subsequent call to ReadFrame.
	f.fr.SetReuseFrames()
	f.fr.MaxHeaderListSize = maxHeaderListSize
	f.fr.ReadMetaHeaders = hpack.NewDecoder(http2InitHeaderTableSize, nil)
	return f
}

// writeBuffer 使用sync.Pool
func getWriteBufferPool(size int) *sync.Pool {
	writeBufferMutex.Lock()
	defer writeBufferMutex.Unlock()
	pool, ok := writeBufferPoolMap[size]
	if ok {
		return pool
	}
	pool = &sync.Pool{
		New: func() any {
			b := make([]byte, size)
			return &b
		},
	}
	writeBufferPoolMap[size] = pool
	return pool
}

type loopyWriter struct {
  // 客户端还是服务端
	side      side
  // controlBuffer
	cbuf      *controlBuffer
  // 发送配额
	sendQuota uint32
  // 发送端初始窗口大小 outbound initial window size
	oiws      uint32
  // 已经建立未清理的stream，在客户端，指所有已经将Headers发送出去的stream，
  // 在服务端，指所有已经接收到Headers的stream
	estdStreams map[uint32]*outStream
  // 活跃stream列表，有数据需要发送且包含stream-level流控，里面的每个stream内部都有一个数据列表用来存放发送的数据
	activeStreams *outStreamList
  // http2.Framer的包装，用来实际读写数
	framer        *framer
	hBuf          *bytes.Buffer  // The buffer for HPACK encoding.
	hEnc          *hpack.Encoder // HPACK encoder.
	bdpEst        *bdpEstimator
	draining      bool
  // 底层tcp连接
	conn          net.Conn
	logger        *grpclog.PrefixLogger
	bufferPool    mem.BufferPool

	// Side-specific handlers
	ssGoAwayHandler func(*goAway) (bool, error)
}

go func() {
  t.loopy = newLoopyWriter(serverSide, t.framer, t.controlBuf, t.bdpEst, t.conn, t.logger, t.outgoingGoAwayHandler, t.bufferPool)
  err := t.loopy.run()
  close(t.loopyWriterDone)
  if !isIOError(err) {
    timer := time.NewTimer(time.Second)
    defer timer.Stop()
    select {
    case <-t.readerDone:
    case <-timer.C:
    }
    t.conn.Close()
  }
}()

func (l *loopyWriter) handle(i any) error {
	switch i := i.(type) {
	case *incomingWindowUpdate:
		l.incomingWindowUpdateHandler(i)
	case *outgoingWindowUpdate:
		return l.outgoingWindowUpdateHandler(i)
	case *incomingSettings:
		return l.incomingSettingsHandler(i)
	case *outgoingSettings:
		return l.outgoingSettingsHandler(i)
	case *headerFrame:
		return l.headerHandler(i)
	case *registerStream:
		l.registerStreamHandler(i)
	case *cleanupStream:
		return l.cleanupStreamHandler(i)
	case *earlyAbortStream:
		return l.earlyAbortStreamHandler(i)
	case *incomingGoAway:
		return l.incomingGoAwayHandler(i)
	case *dataFrame:
		l.preprocessData(i)
	case *ping:
		return l.pingHandler(i)
	case *goAway:
		return l.goAwayHandler(i)
	case *outFlowControlSizeRequest:
		l.outFlowControlSizeRequestHandler(i)
	case closeConnection:
		// Just return a non-I/O error and run() will flush and close the
		// connection.
		return ErrConnClosing
	default:
		return fmt.Errorf("transport: unknown control message type %T", i)
	}
	return nil
}

func (l *loopyWriter) preprocessData(df *dataFrame) {
	str, ok := l.estdStreams[df.streamID]
	if !ok {
		return
	}
	// If we got data for a stream it means that
	// stream was originated and the headers were sent out.
	str.itl.enqueue(df)
	if str.state == empty {
		str.state = active
		l.activeStreams.enqueue(str)
	}
}

type dataFrame struct {
	streamID  uint32
	endStream bool
	h         []byte
	reader    mem.Reader
	// onEachWrite is called every time
	// a part of data is written out.
	onEachWrite func()
}

const (
	// bdpLimit is the maximum value the flow control windows will be increased
	// to.  TCP typically limits this to 4MB, but some systems go up to 16MB.
	// Since this is only a limit, it is safe to make it optimistic.
	bdpLimit = (1 << 20) * 16
	// alpha is a constant factor used to keep a moving average
	// of RTTs.
	alpha = 0.9
	// If the current bdp sample is greater than or equal to
	// our beta * our estimated bdp and the current bandwidth
	// sample is the maximum bandwidth observed so far, we
	// increase our bbp estimate by a factor of gamma.
	beta = 0.66
	// To put our bdp to be smaller than or equal to twice the real BDP,
	// we should multiply our current sample with 4/3, however to round things out
	// we use 2 as the multiplication factor.
	gamma = 2
)

// Adding arbitrary data to ping so that its ack can be identified.
// Easter-egg: what does the ping message say?
var bdpPing = &ping{data: [8]byte{2, 4, 16, 16, 9, 14, 7, 7}}

type bdpEstimator struct {
	// sentAt is the time when the ping was sent.
	sentAt time.Time

	mu sync.Mutex
	// bdp is the current bdp estimate.
	bdp uint32
	// sample is the number of bytes received in one measurement cycle.
	sample uint32
	// bwMax is the maximum bandwidth noted so far (bytes/sec).
	bwMax float64
	// bool to keep track of the beginning of a new measurement cycle.
	isSent bool
	// Callback to update the window sizes.
	updateFlowControl func(n uint32)
	// sampleCount is the number of samples taken so far.
	sampleCount uint64
	// round trip time (seconds)
	rtt float64
}
